Description
Technical Details:
| Receiver | |
|---|---|
| Sensitivity(Analog) | 0.18μV (12dB SINAD) |
| Sensitivity(Digital) | 0.18μV |
| Adjacent Channel Selectivity | ETSI: 60dB@12.5kHz / 70dB@20/25kHz |
| Intermodulation | ETSI: 65dB@12.5/20/25kHz |
| Spurious Response Rejection | ETSI: 70dB@12.5/20/25kHz |
| Blocking | ETSI：84dB |
| Hum&Noise | 40dB@12.5kHz； 43dB@20kHz； 45dB@25kHz |
| Rated Audio Power Output | 0.5W |
| Rated Audio Distortion | ≤5% |
| Audio Response | +1~-3dB |
| Conducted Spurious Emission | <-57dBm |
| Transmitter | |
|---|---|
| RF Power Output | 400-470MHz: 1W/2W/3W (low/medium/high) |
| FM Modulation | 11K0F3E@12.5kHz 14K0F3E@20kHz 16K0F3E@25kHz |
| Conducted/Radiated Emission | -36dBm＜1GHz;-30dBm＞1GHz |
| Modulation Limiting | ±2.5kHz@12.5kHz ±4.0kHz@20kHz ±5.0kHz@25kHz |
| FM Hum&Noise | 40dB@12.5kHz 43dB@20kHz 45dB@25kHz |
| Adjacent Channel Power | 60dB@12.5kHz;70dB@20/25kHz |
| Audio Distortion | ≤3% |
| Environmental | |
|---|---|
| Operating Temperature | -10℃ ~ +55℃ |
| Storage Temperature | -30℃ ~ +70℃ |
| ESD | ±4kV (Contact) ±8kV (Air) |
